Inductor

Description:

An inductor is an electronic component that is used in a printed circuit board (PCB) to store and release energy in the form of magnetic fields. It is typically made up of a coil of wire, which is wound around a magnetic core.

​

Inductors are used in many different electronic circuits to perform a variety of functions, such as filtering out unwanted signals, smoothing out power supplies, and storing energy in resonant circuits. They are also commonly used in DC-DC converters, voltage regulators, and other power electronics applications.

​

In PCB design, inductors can be either through-hole or surface mount components, depending on the size and complexity of the circuit. They are typically represented in schematic diagrams using the symbol of a coiled wire or a series of spirals.

pcb-inductor

Advantages:

  • Energy storage: Inductors can store energy in magnetic fields, which can be released over time. This makes them useful in circuits that require a temporary energy source or need to smooth out voltage fluctuations.

  • Filtering: Inductors can be used to filter out unwanted signals or noise in a circuit. By combining an inductor with a capacitor, you can create a low-pass or high-pass filter, depending on the specific requirements of the circuit.

  • Size and weight: Inductors are generally smaller and lighter than other types of energy storage components, such as capacitors or batteries. This makes them ideal for use in portable or space-constrained devices.

  • Efficiency: Inductors can improve the efficiency of a circuit by reducing losses due to resistance or parasitic capacitance. By storing and releasing energy more efficiently, inductors can help to reduce power consumption and extend the lifespan of a device.

  • Reliability: Inductors are generally very reliable components, with a long lifespan and low failure rate. This makes them a good choice for use in high-reliability applications, such as medical devices, aerospace systems, or automotive electronics.

inductors-for-pcb

Factors Choosing the Right Diode:

  • Inductance value: The inductance value of an inductor can be customized to meet specific requirements of the circuit. This can be achieved by adjusting the number of turns, the diameter and length of the wire, or the type of core material used.

  • Core material: The choice of core material can be customized to optimize the performance of the inductor for a particular circuit. For example, ferrite cores are often used in high-frequency circuits, while powdered iron cores may be better suited for low-frequency applications.

  • Physical dimensions: The physical dimensions of the inductor can be customized to fit within the available space on the PCB. This can involve adjusting the diameter and length of the wire, as well as the number of turns in the coil.

  • Temperature stability: Inductors can be designed to operate reliably over a range of temperatures. This can be achieved by selecting a core material that is stable over a wide temperature range, or by adding thermal insulation or heat sinks to the inductor.

  • Current handling capability: The current handling capability of an inductor can be customized by adjusting the wire gauge and number of turns in the coil. This can help to ensure that the inductor can handle the expected current load without overheating or experiencing saturation.

  • EMI suppression: Inductors can be designed to suppress electromagnetic interference (EMI) in a circuit. This can be achieved by using a shielded core material or by adding additional winding layers to the coil.

inductors-on-pcb

Application:

  • Filtering: Inductors are often used in PCBs to filter out unwanted signals or noise. By combining an inductor with a capacitor, a low-pass or high-pass filter can be created to remove specific frequencies from a signal.

  • Power conversion: Inductors can be used in power electronics applications, such as DC-DC converters and voltage regulators, to store and release energy in the form of a magnetic field. This helps to improve the efficiency and stability of the power supply.

  • RF circuits: Inductors are commonly used in radio frequency (RF) circuits to tune the frequency response of the circuit. They can also be used as part of resonant circuits to store and release energy in a specific frequency range.

  • Sensors: Inductors can be used as part of sensors in PCBs to measure changes in magnetic fields. This is useful in a range of applications, such as detecting the position or motion of an object.

  • Communication: Inductors are used in communication circuits, such as antennas and transformers, to transfer signals between different components of the circuit. They can also be used to filter out interference and improve signal quality.

pcb-inductors

Procurement Process:

  1. Determine the required specifications: The first step is to determine the specifications required for the inductors, such as inductance value, current rating, and physical dimensions. This information will be used to identify potential suppliers.

  2. Send Quotation: Once requirements have been identified, a quotation can be sent to customers including all relevant specifications and quantities required.

  3. Production.

  4. Quality inspection: When the production of the components is finished, it's important to inspect them for quality and to ensure that they meet the required specifications. Any issues should be reported to the supplier immediately.

  5. Delivery.

inductors-on-printed-circuit-board
